NRT40 Rigging Tower
NRT40 Rigging Tower
Designed to fly medium to large PA Line Array systems. The NRT40 tower is made out of standard NH44 Truss elements and a small number of special parts. The PA can be lifted at a height of approx—10 m with the help of an electric chain hoist.
Facts
- Use as a delay tower or main audio rigging tower
- Use standard NH44 Truss
- Static report included
- Small footprint with sufficient space for build-up and subwoofers between the legs
- Minimal transport space as base, outriggers and ballast beams are detachable
Product information
Designed to fly medium to large PA Line Array systems. The NRT40 tower is made out of standard NH44 Truss elements and a small number of special parts. The PA can be lifted at a height of approx—10 m with the help of an electric chain hoist.
The base of the system is the same as NTR30 (with extra girders) and made from a special rigging tower frame that is extended with outriggers and a ballast frame. The outriggers are equipped with extendable spindles to level the construction.
The tower consists of standard truss lengths and a special top part with a cantilever that ensures proper positioning of the PA system. After the tower is assembled, connect it to the base with hinges, and the hoist chain can be put in. The tower is ready to be erected. A special adapter is added to the tower for span cable attachment.
NRT40 Rigging Tower
| Productcode | Description |
|---|---|
| NRT-TOP-PA3 | Top part for PA tower <10mtr |
| NH44-CAP | Adapter part with cable att. |
| NH44-LENGTH | Square truss lengths |
| NT-HINGE-01 | Hinge set for tower NT30 |
| NRT-BASE-PA | Base section for PA tower |
| NRT-BB-I | Ballast beam short |
| NRT-BB-O | Ballast beam long |
| NRT-TES-40 | Erector frame and diagonals |
NRT40-10 PA/ Rigging Tower** 10 Meters
| Specifications | Description |
|---|---|
| Type Tower Truss | NH44 |
| Max. Cantilever Top Part | 1,2 m. |
| Max. Height | 10 m. |
| Max. Load Capacity | 1.000 kg. |
| Amount of Ballast Needed | 3 x 1.000 kg. |
| Max. Windsurface Front | 6,0 m2 |
| Max. Windsurface side | 3 m2 |
